11147 10" Straight Pull Bar

The 11147 10" Straight Pull Bar is part of the Rockwood Hardware

- Push Bar (Length): 30" - 36". Please see below for additional Center-to-Center information.

Features

• Series 47 Straight Single Bar Set
• Engraving "PUSH" or "PULL" (specify handing)

Specifications

• End Shape: Bent
• Grip Shape: Round
• Base Material: Aluminum, Brass, Bronze, Stainless Steel
• Diameter: 1"
• Push Clearance: 1 3/4"
• Ordering: Specify product number, mounting, door type, push bar CTC, and finish (i.e., 11047 T3, wood door, 33" CTC, US32D316)

Optional Base plates available — use BP prefix when ordering

Pull projection is 3-1/2" for stainless steel and 3" for aluminum, brass, and bronze

• Mountings:
  • Metal and Wood: T3 Back to Back and Thru Bolt; Pull Free End = 1, Push Free End = 1, Common End = 5
  • Metal: T4 Back to Back and Concealed; Pull Free End = 6, Push Free End = 6, Common End = 5
  • Wood: T5 Back to Back and Concealed; Pull Free End = 8,Push Free End = 8, Common End = 5
  • Metal and Wood: T1 Back to Back and Decorative Bolt; Pull Free End = 12, Push Free End = 12, Common End = 5
  • Glass: T2 Back to Back and Thru Bolt; Pull Free End = 15, Puss Free End = 15, Common End = 13
  • T3 is the standard mounting method for Metal and Wood Doors (See our mounting selections on this site)


Heavy duty versions of most fastening types available — use suffix HD to fastening type number

Delivery: The 11147 10" Straight Pull Bar is in stock, please allow 1-2 business weeks' lead time.
