Hager 297D-60-52 60in Opening Coordinator Filler Bar Black
Certifications Complies with ANSI A156.3 Type #21A
Fasteners Four #8 x 1" combo screws, Seven 12 - 24 x 1-1/4" TPHMS
Finishes Black Powder Coat
Material 1-5/8" x 5/8" (42 mm x 16 mm) Steel
Notes
- Coordinator may not span the entire length of the stop
- 297F Filler Bar, cut to length by factory to match customer's total opening width, may be needed to fill extra space
- Optional mounting bracket 297B may be used when mounting other soffit applied hardware
- Non-handed
- Compatible with flush bolts
- Do not use spring hinges with coordinating device
- Product Description
- Coordinator with Filler Bar
Stop Height 5/8" (16 mm)
Models
- 297D-60 (for 60″ door openings)
- 297D-72 (for 72″ door openings)
- *297D-96 (for 96″ door openings)
