Lockmaster LKM10814 Plug Follower Tool
- GSA Type: Type II
- Lock: Kaba Mas X-10
- Utilizes electronic access control
- ADA compliant
- Non-handed
- 90 minute fire rating
- Compliance & Certifications
- FF-L-2890C Approved
- GSA Approved
- U.L. Fire Rated
- NFPA 80 & 101 Life Safety
- Replaces LKM7000 & LKM7003
SECURITY FEATURES
Dead Bolt - The FF-L-2890B specification requires a locking device equipped with dead bolt and trigger mechanism that operates when the combination lock is in the locked position. The dead bolt automatically extends into the locked position when the trigger mechanism engages the strike.
Encapsulated Strike - The LKM10K Lock Series comes with a strike that surrounds the dead bolt for reinforced security. As specified four strikes are available for inswing, outswing & pairs of doors.
High Security Combination Lock Compatibility - The LKM10K Lock Series is designed to work with any standard footprint combination lock meeting Federal Specification FF-L-2740B (Kaba Mas X-10 and S&G 2740B). No modificiations to the deadbolt is required.
Access Control Device Compatibility - The LKM10K Lock Series is an electrified lock and is compatible with a variety of electronic access control devices (12v or 24v DC - 1 amp).
Security In Depth - When both the combination lock and access control device are installed with the LKM10K Lock tiers of security are created.
First Tier - FF-L-2740B approved combination lock
Second Tier - Access Control Device or Key Override
Example of Day Locking - The supervisor “unlocks/opens” the combination lock to allow staff to enter throughout the day by utilizing the access control device. The LKM10K Lock Series provides this managerial control. However, once the combination lock is “locked/closed” the access control device and Key Override is negated.
Monitoring Switches - Deadbolt Switch - monitors the Pedestrian Device Bolt (Request to Exit - REX); Combination Lock Switch - monitors the FF-L-2740B Combination Lock Bolt and Entry Monitoring Switch - monitors the Lever Handle
SAFETY FEATURES
Single Motion Egress Handle (Push/Pull Model) - One simple push or pull of the ADA and UFSA compliant handle allows exit. One hand guarantees a safe & easy exit even in emergency situations. (Type II)
Key Override Option - A separate module is no longer necessary for this option. Key Override is standard on all LKM10K Lock Series models. However, it is optional to utilize, so it can be added with little effort at a later date if necessary. We recommend Key Override because it allows a key to “override” the access control device only. It will not override the combination lock. This capability is particularly important during the event of power outage, failure or malfunction of an access control device, or an emergency that requires expedited entry.
UL Fire Rating - The LKM10K Lock Series is UL Listed. 90 minute rating when installed with a Kaba Mas X-10 combination lock. This rating is in accordance with the Standard, "Positive Pressure Fire Test of Door Assemblies", ANSI/UL 10C, UBC 7-2 (1997).
Illuminated Labels - All models of the LKM10K feature an illuminated label for easy visibility in no/low light situations.
